Wuhan J.H. Bio-Tech Co., Ltd.

1. Working mode:

lB, B|B, 4B, B|M, M

lColor blood flow Doppler (CF)

lEnergy Doppler (PDI/DPDI)

lPulse Doppler (PWD)

lContinuous Doppler (CW)

lB+PWD (real-time dual mode)

lB+CF/PDI/DPDI+PWD (real-time triple mode)

lHigh repetition rate (HPRF)

lTissue harmonic imaging (THI)

lComposite imaging

ltrapezoidal imaging

2. Scanning method:
Electronic line array
Electronic convex array
Electronic micro convex
Electronic phased array
Scanning depth: 2-30cm

3. Color Doppler blood flow:
PRF repetition frequency range: 0.5-15KHz
Wall filter range: 3 files adjustable (5%, %10%, 15% PRF)
Line array probe angle deflection: ± 30 °
Real-time spatial filter
CFM color matching >10 kinds
PDI color matching >10 kinds
Color threshold control
CFM baseline control
Doppler frequency adjustable
color frame correlation
Color Transparency Control (TCM)

4. Pulse Doppler:
PRF repetition frequency range: 1-20kHz
Wall filter range: 16 files adjustable (2.5%-20% PRF)
Line array probe angle deflection: ± 30 °

Track spectrum in real time and calculate spectrum parameters in real time
Stereo output
spectrum pseudo color
Doppler frequency adjustable

5. Image processing:
High linear density scanning (adjustable)
8-stage TGC control
Dynamic range >120 dB
Automatic gain control
M scanning speed is adjustable
PW scanning speed is adjustable
adjustable sound power
Controllable frame correlation
gamma correction
Scanning range is adjustable
Up/down/left/right/black and white flip
Image enhancement, edge enhancement
Noise suppression
spot suppression

6. Image, video storage format: AVI, JPG, BMP, PNG, TIF, DCM (DICOM)

7. Routine measurement and calculation: distance, depth, area, perimeter, volume, angle, stenosis ratio, ratio, velocity, gradient (PG), acceleration, resistance index (RI), heart rate, velocity time integral (VTI), etc.

8. Measurement and calculation software package: obstetrics, gynecology, abdomen, urinary, endocrine, blood vessels, heart, etc.

9. Built-in 4D module, optional 4D volume probe

10. Extension interface:
VGA, video output, audio output
USB2.0 interface
RJ-45/DICOM interface
Support inkjet, laser, video printers
